Gear head lathe STUDENT SH-610

Product Code: STUDENT SH-610

PRICES SHOWN ARE EXCLUDING VAT

Regular price €0,00

Gear Head Lathe machine Student SH-610 (610MM BETWEEN CENTERS) features

  • New model compact, small and high precision gear head lathe machine.
  • Features incredible 12 gear spindle speed selection 45-2000rpm.
  • Induction hardened bedways.
  • Automatic feed on both X and Y axis.
  • Well ribbed cast iron bed for rigidity and precision.
  • Wide range of feeds, metric and inch thread cutting.
  • Machine complete with CE safety standards.



Standard accessories that come with the machine

  1. 3 jaw self centering chuck 125mm diameter
  2. 4 jaw independent chuck 125mm diameter
  3. steady rest.
  4. tool box with necessary tools
  5. splash guard
  6. CE safety standards with required safety protections
  7. set of lathe cutting tools
  8. chip tray
  9. machine stand



SPECIFICATIONS
DISTANCE BETWEEN CENTERS 610mm
SWING OVER BED 280mm
SPINDLE TAPER MT4
TAILSTOCK BARREL TAPER MT2
SPINDLE BORE 26mm
CROSS SLIDE TRAVEL 130mm
COMPOUND TRAVEL 75mm
RANGE OF METRIC THREADS 0.25-5mm
SPINDLE SPEED 12 speed 45-2000rpm
POWER OF MOTOR 750w/1hp 220V/50HZ
GROSS WEIGHT 240kgs
RANGE OF IMPERIAL THREADS 6-96tpi
TAILSTOCK QUILL TRAVEL 110mm
