Features:
- Large cutting capacity of max 400mm round bar at 90°
- Saw frame swivel max. up to 60°,
- Hydraulic power to raise and lower the bow up and down with variable down feed.
- Quick clamp, make cutting efficient
- Coolant system extend the saw blade life
- Control panel, easy to operate the machine
- Gear drive band saw
- 2.8kW powerful motor
|
Model
|
BS-2114TH
|
|
|
|
Circular @90°
|
400 mm /16”
|
|
Rectangular @90°
|
550x360mm
|
|
|
Circular @60°
|
150mm
|
|
|
Rectangular @60°
|
250x200mm
|
|
|
Circular @45°
|
340mm
|
|
|
Rectangular @45°
|
400x340mm
|
|
|
Blade speed @ 50Hz
|
48/70m/min
|
|
|
Speed type
|
2 speed motor
|
|
|
Blade size
|
34x1.1x4405 mm
|
|
|
Motor
|
2.2/2.8kw (3PH)
|
|
|
Drive
|
Gear
|
|
|
Packing size (body)
|
230x83x158cm
|
|
|
N.W/G.W
|
630/760KG
|
|
|
|
|
|
